Great Design. Great Performance.
The Spot DUO wall spotlight series combines striking modern design with outstanding performance. Offering 2 x 520 lumens of brightness from just 2 x 7W, this sleek and powerful lighting solution is perfect for illuminating key outdoor areas.
Each spotlight is fully adjustable, with the ability to rotate 180° and tilt 90°, allowing you to direct light exactly where it's needed. Whether used for entryways, pathways, or feature lighting, the Spot DUO ensures precise, stylish illumination.
Key Features:
- Modern Dual Spotlight Design: Sleek, contemporary look with high-quality materials.
- Adjustable Lighting Direction: Spotlights rotate 180° and tilt 90° for precise positioning.
- Smart Motion Detection: Two 90° infrared sensors detect movement up to 10m for automatic lighting.
- Customisable Settings: Adjustable time and twilight thresholds for tailored lighting control.
- Bluetooth Smart Control (SC Model): Wireless connectivity for easy grouping and control via the STEINEL Connect App.
- Energy-Efficient Performance: Delivers high brightness with minimal energy consumption.
- Replaceable LED Bulbs Included: Comes ready to install with high-quality LED lamps.
For those seeking smart lighting, the Spot DUO SC offers Bluetooth-based control, allowing lights to be grouped and managed conveniently via app. Whether for security, ambiance, or architectural lighting, the Spot DUO series provides a stylish and highly functional solution.
| Category | Specification |
|---|---|
| Dimensions (L x W x H) | 175 x 247 x 98 mm |
| With lamp | Yes, LED lamp |
| With motion detector | Yes |
| Manufacturer's Warranty | 3 years |
| Settings via | Potentiometers |
| Version | With motion detector |
| PU1, EAN | 4007841058647 |
| Application, place | Outdoors |
| Application, room | Outdoors, all around the building, terrace/balcony, courtyard & driveway |
| Colour | Anthracite |
| Includes corner wall mount | No |
| Installation site | Wall |
| Installation | Wall, Surface wiring |
| Impact resistance | IK03 |
| IP-rating | IP44 |
| Protection class | I |
| Ambient temperature | From -20 up to 40 °C |
| Housing material | Aluminium |
| Cover material | Plastic, transparent |
| Mains power supply | 220 – 240 V / 50 – 60 Hz |
| Output | 14.95 W |
| Mounting height max. | 2.50 m |
| Sneak-by guard | No |
| Capability of masking out individual segments | No |
| Electronic scalability | No |
| Mechanical scalability | No |
| Reach, radial | r = 2 m (3 m²) |
| Reach, tangential | r = 10 m (79 m²) |
| Optimum mounting height | 2 m |
| Detection angle | 90° |
| Photo-cell controller | Yes |
| Luminous flux total product | 1024 lm |
| Measured luminous flux (360°) | 1024 lm |
| Total product efficiency | 68.5 lm/W |
| Colour temperature | 3000 K |
| Colour variation LED | SDCM5 |
| Lamp | LED can be replaced |
| Service life LED L70B50 (25°) | > 20000 h |
| Soft light start | No |
| Continuous light | Selectable |
| Colour Rendering Index (CRI) | = 81 |
| Article number | 058647 |
| European Article Number (EAN) | 4007841058647 |
| Twilight setting | 2 – 1000 lx |
| Time setting | 8 s – 35 min |
| Basic light level function | No |
| Main light adjustable | No |
| Twilight setting TEACH | No |
| Interconnection | Yes |
| Interconnection via | Cable |
| Product category | Sensor-switched LED floodlight |
